Bitwise AND, Computations, and Examples
A Bitwise AND is a binary operation that takes two equal-length binary representations and performs the logical AND operation on each pair of the corresponding bits. This is equivalent to multiplying them.
Table of Contents
Here, we discuss the '&' operator in more detail.
Introduction
A Bitwise AND is a binary operation that takes two equal-length binary representations and performs the logical AND operation on each pair of the corresponding bits. This is equivalent to multiplying them.
Bitwise ANDing any number x with 0 yields 0
Bitwise AND
The Bitwise AND operator does the following:
- It is a binary operator that takes two numbers.
- When we do Bitwise & of these two numbers, it considers the binary representation of these two numbers.
- Bitwise AND compares bit by bit in binary representation, and whatever binary representation you get, the corresponding integer is returned as an output.
The integer data type takes 4
bytes in C, C++, and Java programming languages.
4 bytes = 4 * (8 bits) = 32 bits. {1 byte = 8 bits}
Example
Let’s see one of the above examples in binary representation.
For simplicity, let’s represent these in 16-bit instead of 32-bit binary.
a = 12
b = 10
---------------------------------
a in Binary : 0000 0000 0000 1100
b in Binary : 0000 0000 0000 1010
---------------------------------
a & b : 0000 0000 0000 1000
---------------------------------
The &
operation starts from the rightmost bit traversing towards the leftmost bit in the 32-bit binary representation.
Illustration
Let’s visualize the steps below.
Below is a code representation of the &
operator.
Code
Java
class AndOperation {
public static void main( String args[] ) {
int x = 12;
int y = 10;
System.out.println("Bitwise AND of (" + x + " , " + y + ") is: " + (x & y)); // yields to 8
}
}
// Outputs: Bitwise AND of (12 , 10) is: 8
Python
x = 12
y = 10
print("Bitwise AND of (x ,y) is : ", (x & y))
# Output: Bitwise AND of (x ,y) is: 8
JavaScript
const AndOperation = (x, y) => {
return x & y;
}
const x = 12;
const y = 10;
console.log (`Bitwise AND of (${x}, ${y}) is: ${AndOperation (x, y)}`);
// Output: Bitwise AND of (12, 10) is: 8
C++
#include <iostream>
using namespace std;
int main() {
int x = 12;
int y = 10;
cout << "Bitwise AND of (x ,y) is: " << (x & y); // yields to 8
return 0;
}
// Output: Bitwise AND of (x ,y) is: 8
TypeScript
export const AndOperation = (x: number, y: number): number => {
return x & y;
}
const x: number = 12;
const y: number = 10;
console.log(`Bitwise AND of (${x}, ${y}) is: ${AndOperation(x, y)}`);
// Output: Bitwise AND of (12, 10) is: 8
We will apply the Bitwise approach to solve a few problems in the following lessons.
Let’s jump into our first problem with the Bitwise &
operator.
